Ford EVs now include convenient mobile chargers for easy charging using standard household outlets. It has two options: a standard 120V and a 240V home outlet. In this blog, we will explore the Ford mobile charger manual that decodes innovative charging solutions along with their specs, enabling sustainable transportation.

Ford Mobile Charger Manual

The Ford Mobile Charger is a versatile and easy-to-use power supply designed for quick charging of electric vehicles. This charger is backed with a three-year limited warranty and is compatible with all J1772 plugs, which are the industry standard for electric vehicles.

The following are the main characteristics of the Ford mobile charger:

  • Simple to use, compact, and portable design.
  • Efficient AC Power supply for electric vehicles.
  • Versatile charging options (120V and 240V Connectors).
  • Safety features include built-in overheating and overvoltage protection.
  • Quick status indicators lights for charging progress.

Ford’s all-electric cars have the versatile Ford Mobile Charger, which supports Level 1 and Level 2 charging and provides up to 30 amps of charging power. This manual will walk you through the Ford mobile charger specs, its installation, and operation, guaranteeing a seamless charging experience for your Ford electric vehicle.

Ford Mobile Charger Specs

JAN23 Ford Mobile Charger Manual 1

It has two charging options: a 240V NEMA 14-50 outlet, which provides 20 miles of range per charging hour, and a standard 120V home outlet, which provides 3 miles of range per charging hour. Now, let us go through the parameters of the NEMA 14-50 outlet.

Ford NEMA 14-50 Outlet Specifications

The NEMA 14-50 outlet offers a safe and dependable way to charge your electric vehicle at home. Further details about NEMA 14-50 outlet are listed below, take a look:

ParametersValues
Charger Model  SAE
Voltage  120-240 VAC
Maximum Current  32 amps max continuous
Frequency  60Hz
Power draw when idle  < 2 Watts
Power draw when charging  < 4 Watts
Cable length  Approximately 20 ft.
Weight  8.6 lb.
Operating temperature  -22°F to 122°F
Storage temperature  -22°F to 185°F
CCID Environmental  IP67
Ventilation  Not required

You must consult a professional for the installation. Even if you are charging at home, it is recommended that you contact a licensed electrician to avoid any mishappenings.

EV charger
By Getty Images from Unspalsh+

Since you are aware of the NEMA 14-50 outlet, for better understanding go through the comparison table of different outlets.

ParametersPlugged into 240V/32A NEMA 14-50 Wall OutletPlugged into 120V/12A Wall Outlet
Standard with Mustang Mach-E ModelYesYes
Charging Power (amps)3212
Charging Time (0%-100%)†15 hours95 hours
Average Range per Charging Hour†20 miles3 miles
Outlet InstallationRequires professional installation by a licensed electrician — Ford recommends QmeritStandard home or garage outlet

These charging options enable you to charge overnight, ensuring that you begin each day with the electric equivalent of a full tank.

Also Read: What Kind of Chargers can Mach-E Use?

Ford Mobile Power Cord Specs

JAN23 Ford Mobile Charger Manual 2

The Ford Mobile Power Cord can be employed with any electric vehicle that has an SAE J1772 connector. It can be plugged into a standard 120V outlet or a 240V NEMA 14-50 outlet; here are the specifications:

SpecificationValue
ConnectorIndustry-standard/universal SAE J1772 connector (Compatible with SAE J1772-compliant electric vehicles)
Output (SAE)Up to 7.36 kW/32-amp
Dynamic Color LED LightsShow power and charging status
UsageCapable for both indoor and outdoor use
IP RatingIP-66 when connected
Cable Length20 ft.
Input Voltage120V or 240V
Input Frequency60Hz
Weight9.5 lbs

Also See: Power Bank Solar Charger Instructions: User Manual for Portable Charging

How to Charge Your Ford EV with Ford Mobile Charger

Installing and operating the Ford Mobile Charger is a simple process. The charger can be easily found in the rear luggage compartment, beneath the load floor, making it easy to charge your vehicle’s battery using average household electricity.

The Ford mobile power cord package comprises:

  • Cord and charges coupler
  • A low power connector (120V)
  • A high power connector (240V NEMA 14-50)
  • A wall bracket

To start charging your electric vehicle, first, connect the connector to the control box, home outlet, and then to your vehicle’s charge port. If you are wondering about its connection to a regular outlet, check out our blog – Can You Plug an Electric Car Into a Regular Outlet?

When correctly connected, the power indicator will illuminate, indicating that the charger is actively providing power to your electric vehicle. The Ford Mobile Charger includes the following indication lights:

  • The Amber Fault Indicator Light indicates the need to reboot after an error.
  • The blue status indicator light indicates when the charger is ready to use, showing that it is inserted into a wall outlet.

Step-by-Step Charging Process:

EV charger 2
By Getty Images from Unspalsh+

In this Ford mobile charger manual, now we are going to understand the step-by-step charging process:

Step 1: Place the Ford Mobile Charger bracket near the selected 120V or 240V outlet.

Step 2: Connect the appropriate 120V or 240V connector to the mobile charger.

Step 3: Plug the mobile charger connector into a 120V or 240V outlet.

Step 4: Securely connect the mobile charger to the wall-mounted bracket.

Step 5: Connect the mobile charger cord set coupler to a Ford vehicle such as Mustang Mach-E charging port.

Unless it is outside of the pre-scheduled charge hours, charging will begin automatically.

It has been recently in the news that EV Charging Cable Theft has become rampant. Read these 16 clever ways to protect yourself from EV charging cable theft.

Ford Mobile Charger Price

Prices for the Ford Mobile Charger are as follows:

  • Ford Mobile Charger: 3.0l, priced at around $421.85
  • Ford Mobile Charger Charging Cable: 3.0l, priced at around $378.67.

Note: Ford mobile charger prices are subject to change, therefore it is best to contact a dealer for the most up-to-date information.

To sum up, Ford mobile charger manual provides essential guidance for charging your EV conveniently, both at home and on the go. With its specifications, you can now enjoy the benefits of eco-friendly and efficient transportation. For more intriguing EV content, check out our website.

Source: FORD MOBILE CHARGER Official PDF
